E35SE24006PDPG Isolated Module DC DC Converter Module Delta Electronics

Delta E35SE24006PDPG is a high-efficiency DC/DC power module designed for industrial and commercial applications.

Based on Delta’s E35SE series specifications and industry-standard power electronics,

this component is optimized for reliable energy conversion in harsh environments.

Core Functionalities

1. Power Conversion
   • Converts input voltages (9–60V DC) to a stable 24V DC output with a rated current of 6A (inferred from the "24006" suffix), delivering up to 150W of power .
   • Achieves 92.2% efficiency, minimizing energy loss and heat generation for prolonged operation in enclosed systems.
2. Protective Features
   • Overvoltage Protection (OVP): Automatically disconnects output during voltage spikes to prevent damage to connected equipment.
   • Overcurrent Protection (OCP): Limits current to safe levels during short circuits or overloads.
   • Thermal Shutdown: Deactivates the module if internal temperatures exceed +105°C, ensuring safety in high-heat environments .
3. Electrical Performance
   • Supports 4242V DC isolation for robust protection against electrical noise and ground loops, critical for sensitive industrial controls.
   • Maintains low output ripple (<1% of nominal voltage) for stable power delivery to precision devices like PLCs and sensors.
4. Rugged Design
   • Housed in a 1/8 brick form factor (58.4 x 22.8 x 13.5 mm) with a metal casing, offering resistance to vibration, dust, and moisture (IP20-rated).
   • Operates across a wide temperature range (-40°C to +85°C), making it suitable for extreme climates .
5. Flexible Integration
   • Compatible with open-frame, potted, or flanged enclosures (PDPG suffix likely denotes a specific packaging variant).
   • Supports parallel operation for redundancy in mission-critical systems.

Typical Applications

1. Industrial Automation
   • Machine Tools: Powers CNC machines, robotics, and PLCs in manufacturing plants, ensuring stable 24V supply for control systems.
   • Process Control: Integrates with sensors, actuators, and HMIs in chemical or pharmaceutical facilities, adhering to EN 61000-6-2 standards for industrial immunity.
2. Renewable Energy
   • Solar Inverters: Converts variable DC voltages from solar panels to stable 24V outputs for auxiliary systems like monitoring and cooling fans.
   • Wind Turbines: Provides power to pitch control systems and remote monitoring units in nacelles, with temperature tolerance for offshore environments.
3. Telecommunications
   • Base Stations: Stabilizes power for RF amplifiers and backhaul equipment in 5G networks, supporting wide input voltage ranges common in remote locations.
   • Data Centers: Delivers clean DC power to server racks and network switches, minimizing downtime through high-efficiency conversion.
4. Transportation
   • Rail Systems: Powers onboard electronics (e.g., passenger displays, door controls) in trains, meeting EN 50155 standards for vibration and temperature extremes.
   • Electric Vehicles (EVs): Used in battery management systems (BMS) to regulate auxiliary power for heating, ventilation, and air conditioning (HVAC).
5. Medical Equipment
   • Diagnostic Tools: Provides isolated 24V power for MRI scanners and lab instruments, ensuring compliance with IEC 60601-1 for medical safety.

Technical Specifications (Generalized)

• Input Voltage: 9–60V DC.
• Output Voltage: 24V DC ±1%.
• Output Current: 6A (150W max).
• Efficiency: Up to 92.2% .
• Isolation: 4242V DC.
• Operating Temperature: -40°C to +85°C.
• Dimensions: 58.4 x 22.8 x 13.5 mm (1/8 brick).
• Certifications: CE, UL 62368-1 (pending, based on Delta’s compliance history).

E35SE24006PDPG Isolated Module

E35SE24006PDPG DC DC Converter Module

Delta Electronics E35SE24006PDPG
